Ultra-efficient Type
Saving your money from heavy bills
First Class Efficiency
Atlas Copco Same Performance
Built on proven Atlas Copco group technology and supported by original Bolaite components.
Need a compressor match?
Share your air demand, pressure and site conditions. Our engineers will recommend the right model.
The BLT L series is not just a ground-breaking new compressor range, it is an operational transformation. It reduces your energy costs by 50% on average and maximizes uptime, even in the harshest conditions. Driving this next-level performance: Atlas Copco’s Variable Speed Drive, a powerful interior permanent magnet motor, and our in-house developed Neos inverter.
Features
Bolaite air compressor could bring you:
- Long-life consumables intervals
- Quite Enclosure to 66 dBA
- Atlas Copco’s airend(rotors)
- Atlas Copco touch screen color controller
- Main component from Atlas Copco for reliable performance
Which air compressor best suits you?
Max. working pressure
3.5-5.5 bar
Capacity FAD*
4.9-55 m3/min
Installed motor power*
55-250 kw
On the Whole
First class energy efficiency Low pressure 3.5-5.5bar Suitable for low pressure industry Ease of serviceability
Look Closer
Vacuum inlet valve High efficient motor Installed Atlas Copco’s high-efficiency airend Atlas Copco touch screen color display controller
Atlas Copco airend
Installed with Atlas Copco’s airend Special designed for low pressure applications SKF heavy-duty bearings ensure long life and reliable operation
High Quality Motor
IP55 protection fully enclosed motor Efficient design, SKF bearings ensure long life of the motor Standard reverse rotation protection
Atlas Copco inverter
Atlas Copco designed inverter Fast response to fluctuate air demand Wide frequency range for minimum loss
High efficient oil separator
Reduce oil content to less than 2ppm Effectively reduce pressure loss Provide you with clean compressed air
Atlas Copco controller
Installed with Atlas Copco’s controller Touch screen with IP54 protection, CSA and UL certified
Vaccum inlet valve
Atlas Copco vacuum inlet valve Less pressure loss, increase energy efficient
Filtering system
Heavy duty inlet air filter system Provide clean air for your system
Full protection
Pre-filter system installed Protect system for heavy particles
Outstanding Energy Efficiency; Consistent Performance
Installed with high quality Atlas Copco airend(screw element)
-
- The heart of the compressor-airend(screw element) is installed with Atlas Copco. With Atlas Copco high quality and high-performance airend, Bolaite air compressor could keep your compressed air system running efficiently, effectively and operating at full capacity.
Strictly Follows European Industrial Design and Testing Standards
- Following Atlas Copco’s excellent design capability and abundant experience for air compressors, Bolaite compressor keeping the best balance between performance and cost. The strict development process and testing standards which have been formed with reference to the Atlas Copco’s experience accumulated over decades, ensure reliable quality of every Bolaite air compressor.
ISO International Standard Quality Management System
- Bolaite air compressors are kept in strict conformity with the ISO9001, ISO14001 and OHSAS18001 standards from design, manufacturing to assembly, so as to ensure stable operation of the compressor, and thus the interests of the user in the long run.
- Benefiting from the Atlas Copco’s history and technical experience for over 140 years, and designed specifically for the variety of complex climates and poor working conditions in China, every BLT-series air compressor provides the best quality assurance.
| Model | Max. pressure | Capacity FAD | Motor power | Noise level | Weight | Air outlet | Dimensions (mm) |
| bar(e) | m3/min | kW | dB(A) | kg | LxWxH | ||
| BLT-75AG L | 5 | 12.9 | 55 | 75 | 2600 | DN100 | 2845x1750x1930 |
| BLT-100AG L | 5 | 17.9 | 75 | 75 | 2900 | DN100 | 2845x1750x1930 |
| BLT-120A L | 5 | 22.7 | 90 | 75 | 3040 | DN100 | 2845x1750x1930 |
| BLT-150A L | 5 | 25.9 | 110 | 77 | 3240 | DN100 | 2845x1750x1930 |
| BLT-175A L | 5 | 29.5 | 132 | 77 | 3300 | DN100 | 2845x1750x1930 |
| BLT-200A L | 5 | 37.3 | 160 | 78 | 4300 | DN125 | 4800x2150x2250 |
| BLT-250A L | 5 | 43.2 | 180 | 78 | 4800 | DN125 | 4800x2150x2250 |
| BLT-275A L | 5 | 47.3 | 200 | 78 | 5325 | DN125 | 4800x2150x2250 |
| BLT-350A L | 5 | 55.0 | 250 | 78 | 5895 | DN125 | 4800x2150x2250 |
Note:
Above model could operate between 3.5-5.5bar
| Model | Max. pressure | Capacity FAD | Motor power | Noise level | Weight | Air outlet | Dimensions (mm) |
| bar(e) | m3/min | kW | dB(A) | kg | LxWxH | ||
| BLT-75AG L VFC | 5 | 4.9-12.9 | 55 | 75 | 2840 | DN100 | 2845x1750x1930 |
| BLT-100AG L VFC | 5 | 7.1-17.9 | 75 | 75 | 3140 | DN100 | 2845x1750x1930 |
| BLT-120A L VFC | 5 | 9-22.7 | 90 | 75 | 3280 | DN100 | 2845x1750x1930 |
| BLT-150A L VFC | 5 | 10.7-25.9 | 110 | 77 | 3350 | DN100 | 2845x1750x1930 |
| BLT-175A L VFC | 5 | 12-29.5 | 132 | 77 | 3350 | DN100 | 2845x1750x1930 |
| BLT-200A L VFC | 5 | 14.9-37.3 | 160 | 78 | 4500 | DN125 | 4800x2150x2250 |
| BLT-250A L VFC | 5 | 15.7-43.2 | 180 | 78 | 5000 | DN125 | 4800x2150x2250 |
| BLT-275A L VFC | 5 | 18.1-47.3 | 200 | 78 | 5525 | DN125 | 4800x2150x2250 |
| BLT-350A L VFC | 5 | 21-55 | 250 | 78 | 6095 | DN125 | 4800x2150x2250 |
Note:
Above model could operate between 3.5-5.5bar
